Gast Piston Air Comp-Vacuum Pump,2 hp,3 Phase 8HDM-251-M853

The Gast 8HDM-251-M853 is an oil-free, four-cylinder piston air compressor/vacuum pump with a reciprocating design. It operates on 230/460V AC three-phase power at 60 Hz at a rated 2 hp output, in a tankless configuration. The oil-free design means the compression chamber runs without lubricant. It provides a free-air delivery ranging from 7.0 CFM at 100 psi up to 11.0 CFM at 0 psi, and a maximum continuous pressure of 100 psi. It has a maximum speed of 1,725 RPM, a full-load current of 6.6/3.3 A, and a measured sound level of 74 dBA. The operating temperature range is 32 to 104°F. Construction includes an aluminum cylinder, an open drip-proof motor, and stainless steel valves. Air connections are 3/8 in NPT inlet and outlet. Overall dimensions are 22.375 x 12.375 x 8.75 in (L x W x H). Duty cycle: continuous.
