Gast Piston Air Compressor-Vacuum Pump,1-6HP 1LAA-251-M100X

The Gast 1LAA-251-M100X is an oil-free, single-cylinder piston air compressor/vacuum pump with a reciprocating design. It operates on 115V AC single-phase power at 60 Hz at a rated 1/6 hp output, in a tankless configuration. The oil-free design means the compression chamber runs without lubricant. It provides a free-air delivery ranging from 0.9 CFM at 50 psi up to 1.51 CFM at 0 psi, a maximum continuous pressure of 50 psi, and a maximum vacuum of 26 in Hg. It has a maximum speed of 1,725 RPM, a full-load current of 4.3 A, and a measured sound level of 75 dBA. The operating temperature range is 32 to 104°F. Construction includes a cast iron cylinder, a split-phase motor, and stainless steel valves. Air connections are 1/4 in NPT inlet and outlet. Overall dimensions are 11.625 x 5.625 x 8.5 in (L x W x H).
