Check Valve, 2483SC Series, Inline Swing, 1 1-2 in, FNPSM x FNPSM, Carbon Steel 4371001260

SHARPE 4371001260 is an inline swing check valve for one-direction flow applications and reverse-flow reduction. Listed application types include corrosive chemical, flammable service, process piping, and toxic media applications. The valve features a carbon steel body, threaded female NPSM connections on both ends, and horizontal or vertical mounting. Key Features: Valve type: 2-way check valve with inline swing mechanism and inline body style Size: 1 1/2 in nominal valve size and pipe/tube size Connections: 1 1/2 in female NPSM on both ends; threaded x threaded Body material: Carbon steel Internal materials: 316 stainless steel check mechanism and spring Seal and seat: 304 stainless steel and graphite seal material; metal seat Pressure rating: Maximum operating pressure 1,465 psi Temperature rating: Maximum operating temperature 650 degrees F Flow coefficient: Cv 55 Mounting: Horizontal or vertical orientation Dimensions: 4.72 in overall length; cap to inlet center 1 23/25 in; height cap to inlet center 1 15/16 in Standards: API 602, NACE MR0175 Series: 2483SC
