IEC Miniature Magnetic Contactor, 1NO, 110V AC, 3 P, Non-Reversing, Screw Clamp LC1K0610F7

The Schneider Electric IEC Miniature Magnetic Contactor is a 3-pole, non-reversing, electrically operated switching device (TeSys series) with a 110 V AC coil. It has three normally open main contacts and one normally open auxiliary contact, and uses screw clamp terminals for wiring. Suitable for motor control applications within specified parameters, it mounts on DIN rails or plates and ships without an enclosure; the user should provide an appropriate enclosure as needed. - Action: Non-Reversing - Application: Motor Control - Coil Voltage: 110 V AC - Main Contacts: 3 NO - Auxiliary Contacts: 1 NO (Includes Auxiliary Contacts) - Frame/Series: TeSys - Contactor Style: IEC - Mounting: DIN Rail, Plate - Electrical Connection: Screw Clamp Terminals - Enclosure: No Enclosure - IP Rating: IP22 - Frequency: 50/60 Hz - Rated Voltage: Rated for operation at voltages up to 690 V AC within specified conditions - Inrush VA: 30 VA - Hold VA: 4.5 VA - Tightening Torque: 0.8–1.3 Nm - Net Weight: 0.18 kg - Dimensions (W x H x D): 1.77 in x 2.28 in x 2.24 in - Mechanical Durability: 10 Mcycles - Electrical Durability: 1.3 Mcycles - Full Load Current (Inductive/Resistive): Rated for use with loads up to 6 A (inductive) and 15 A (resistive) under specified conditions - Rated Making Capacity: Has a rated making capacity of up to 110 A under standard test conditions - Standards: BS 5424, CSA, IEC 60947, NF C 63-110, UKCA, UL Listed, VDE 0660 - Includes Auxiliary Contacts: Yes
