IEC Magnetic Contactor, 1NC-1NO, 110V AC, 3 P, Non-Reversing, Screw Clamp LC1D12F7

The item is an IEC Magnetic Contactor (TeSys Deca) with three poles and a 110 V AC coil. It is a non-reversing device with 1 normally open and 1 normally closed auxiliary contacts (2 total), and uses screw clamp terminals for wiring. Rated for switching power circuits within the specified IEC standards. It is suitable for use with motor control and resistive loads when used according to manufacturer instructions, and is provided without an enclosure; rated IP20 for indoor use only. Key features - Coil voltage: 110 V AC - Poles/Main contacts: 3 main normally open contacts - Auxiliary contacts: 2 total (1NO/1NC) - Reversing: Non-Reversing - Electrical connection: Screw Clamp Terminals - Series/Frame: TeSys Deca (IEC) - Frequency: 50/60 Hz - Maximum voltage rating: 690 V AC - Full Load Amps: 25 A (resistive); 12 A (inductive) - Enclosure: No Enclosure; IP20 (indoor use only) - Weight: 0.325 kg - Dimensions: Depth 3.39 in; Height 3.03 in; Width 1.77 in - Mounting: DIN Rail, Plate; Mounts On: Plate, Rail - Protective cover: Includes protective cover - Standards: EN 60947-4-1, EN 60947-5-1, UL 508, UL Listed, CSA, CSA C22.2 No 14, and others
