IEC Magnetic Contactor, 1NC, 120V AC, 3 P, Non-Reversing, Screw XTCE032C01A

The Eaton XT IEC Magnetic Contactor is an IEC-standard, three-pole, non-reversing magnetic contactor with a 120 V AC coil. It is rated for operation within the specified current range of 32 A and includes one auxiliary contact (1NC). The unit is constructed according to the XT series specifications with frame size C and supports mounting on DIN rails or panels using screw terminals. Key features - Poles: 3; Action: Non-Reversing; Reversing: No - Coil voltage: 120 V AC; Amperage rating: 32 A - Auxiliary contacts: 1 NC (Auxiliary Contact Configuration: 1NC; Form: 1NC) - Mounting: DIN Rail, Panel; Terminal connection: Screw - Frame/Series: Frame C; Series XT; IP Rating: IP20; Enclosure: No Enclosure - Maximum voltage: 690 V AC; Frequency: 50/60 Hz; Certifications: UL Listed; CSA Certified; IEC 60947; EN 60947; CE Marked; RoHS - Dimensions: Width 3.5 in; Height 2.0 in; Depth 4 in - Electrical durability: 300 (AC-4 400V Ie), 800 (AC-1 400V Ie), 800 (AC-3 400V Ie); Mechanical durability: 10,000,000 cycles - Operating temp: Max 122°F; Min operating temp: Not Rated in provided data - Includes auxiliary contacts: Yes (1)
