IEC Magnetic Contactor, 1NC, 120V AC, 3 P, Non-Reversing, Screw XTCE015B01A

The EATON - IEC Magnetic Contactor is a non-reversing contactor with a 1NC auxiliary contact form. It operates on a coil voltage of 120V AC and has an amperage rating of 15A for inductive loads and 22A for resistive loads. The product, which adheres to the standards set by CE, CSA, EN 60947, IEC 60947, RoHS, and UL Listed certifications, features screw terminals for electrical connection. With no enclosure as per its NEMA rating, it can be mounted either on DIN Rail or Panel. Key Features: - Non-Reversing Action: This feature means that the magnetic contactor cannot reverse its direction. - Coil Voltage: Operates at a coil voltage of 120V AC. - Amperage Rating: Can handle up to 15A for inductive loads and up to 22A for resistive loads. - Certifications: Complies with multiple international standards including CE Marked; UL Listed; CSA Certified; IEC & EN standard -60947. - Electrical Connection: Uses screw terminals for making electrical connections. - Mounting Style: Versatile mounting options include both DIN Rail and Panel mountings. - Operating Cycles: The product has been tested for up to one million electrical operations and ten million mechanical operations under standard conditions. - Horsepower Compatibility: Compatible with varying horsepower ratings, ranging from single-phase (1 hp @120V AC) to three-phase (10 hp @480V AC), based on the manufacturer's specifications.
