IEC Magnetic Contactor, 1NC, 120V AC, 3 P, Non-Reversing, Screw XTCE012B01A

The Eaton XT IEC contactor is an IEC magnetic contactor rated for controlling power circuits within specified parameters. It is a 3-pole, non-reversing device with a 120 V AC coil, featuring one auxiliary contact (1NC) and screw terminals. The unit uses a frame size B and is compatible with DIN rail or panel mounting according to IEC standards. - Coil voltage: 120 V AC - Action: Non-Reversing - Poles and auxiliary: 3 poles; 1NC auxiliary contact - Auxiliary contact form: 1NC - Reversing: No - Rated for operation up to 690V AC within specified conditions - Full load current: 12 A (inductive); 22 A (resistive) - rated for full load currents of up to 12A (inductive) and 22A (resistive) under specified conditions - HP ratings: suitable for applications requiring the indicated horsepower ratings at specified voltages, within the product's electrical specifications - IP rating: IP20 - Mounting style: DIN Rail, Panel - Enclosure: No Enclosure - Certifications/Standards: UL Listed; CSA Certified; CE Marked; EN 60947; IEC 60947; RoHS - Durability: tested for a minimum of 10,000,000 mechanical cycles and 1,000,000 electrical cycles under standard testing procedures - Response time: has response times as specified under test conditions - Series/Frame: XT; Frame Size B - Product name: Eaton XT IEC contactor
