Snap Action Switch - SPDT, Short Lever, 11A 250V AC, Quick Connect Terminals V7-1B17D8-122

Honeywell’s MICRO SWITCH V7 Miniature Snap Action Switch is constructed with a housing. This switch features a short straight lever actuator and supports single-pole double-throw (SPDT) operation, making it suitable for use in various on/off limit or presence/absence sensing applications. The device features quick connect terminals for straightforward installation and is constructed with a polyester body. Key Features: - Actuator Type: Short straight lever, 1.63" length - Contact Form: SPDT (1NO/1NC) - Electrical Ratings: AC—11A @ 250V; DC—0.5A @ 125V, 0.25A @ 250V - Operating Force: Maximum 1.5 ozf (0.42N) - Travel Parameters: Pretravel—0.236", Overtravel—0.118", Differential travel—0.053" - Mounting Dimensions: 0.87" centers, mounting hole diameter of 1/8" - Body Size: Width—1.14", Height—0.63", Depth—0.4" - Housing Material: Polyester - Temperature Range: -40°F to +185°F standard; options up to +347°F available - Terminal Type: Quick connect (3/16") - Standards Compliance: CSA, ENEC, RoHS, UL Listed
