Snap Action Switch - V7 Series, SPDT, Lever Roller, 11A, Miniature V7-1B17D8-263

Honeywell’s MICRO SWITCH V7 Miniature Snap Action Switch features a simulated roller lever actuator and is rated for use in compact spaces according to manufacturer specifications. The switch utilizes a polyester housing and offers single-pole double-throw (SPDT) contact configuration, making it suitable for various on/off limit or presence/absence sensing tasks. It operates with an actuation force of 3.17 ozf and supports both AC and DC voltage ratings. Key Features: - Actuator: Lever, Simulated Roller; length 1.29" - Contact Form: SPDT (1NO/1NC) - Electrical Ratings: 11A @ 125–277V AC; 0.5A @ 125V DC; 0.25A @ 250V DC - Body Dimensions: Width 1.14", Height 0.63", Depth 0.4" - Housing Material: PCT Polyester - Mounting Centers: 0.87" with mounting hole diameter of 1/8" - Operating Temperature Range: -40°F to +185°F (-40°C to +85°C) - Terminal Type: Quick Connect, Spade Tab (0.188" wide x 0.020" thick) - Differential Travel Max.: 0.03"; Pretravel Max.: 0.11"; Overtravel Max.: 0.06" - Standards Compliance: CSA, ENEC, RoHS, UL Listed
