Aignep Usa Quick Disconnect Fitting,Clamp,1-4,Brass 80193-08

The AIGNEP USA - 80193-08 is a quick-connect hose coupling designed for use in compressed air systems and with air tools. It features a push/pull sleeve locking mechanism to support connection and disconnection of hoses or equipment with a sealed connection when installed using compatible hoses and fittings. Constructed from brass with a nickel-plated finish, this coupling is compatible with specified quick-connect interchange standards (see compatibility specifications) and includes a poppet valve to regulate air flow during connection and disconnection. The fitting caters to a hose barb connection style with a barb size of 1/2 inch and a quick connect body size of 1/4 inch. Key Features: - Coupling Size: 1/4 in with Hose Fitting Size: 1/2 in, Male gender - Material: Brass with nickel-plated finish - Includes nickel-plated brass body, stainless steel locking balls, and a protected seal - Maximum rated flow rate: 595 liters per minute (under specified flow conditions) - Maximum rated working pressure: 250 psi at 70°F - Operating temperature range: 0°F to 160°F - Overall length: 2.44 inches - Maximum outside diameter: 15/16 inch - Seal material: Nitrile - Connection Type: Hose Barb - Coupling Component: Socket - Locking Type: Sleeve
