IEC Miniature Magnetic Contactor, 2NC, 120V AC, 3 P, Reversing, Screw Clamp LC2K0601G7

The SCHNEIDER ELECTRIC IEC Miniature Magnetic Contactor is a 3-pole, reversing-action device rated for use in motor control and low-power applications within specified parameters. It has a 120 V AC coil and includes two normally closed auxiliary contacts (2 NC) along with three normally open main contacts, all arranged for screw clamp terminals. This IEC-style contactor is part of the TeSys K series and is supplied without an enclosure; suitable for indoor installation in protected environments. - Action: Reversing - Application: Motor Control - Coil Voltage: 120 V AC - Contactor Style: IEC - Poles: 3 - Main Contacts: 3 normally open - Auxiliary Contacts: 2 NC - Electrical Connection: Screw Clamp Terminals - Series: TeSys K - Maximum Voltage Rating: 690 V AC - Frequency: 50/60 Hz - Rated Currents: 6 A inductive; 15 A resistive (Full Load) - Electrical Durability: 1.3 Mcycles - Mechanical Durability: 5 Mcycles - Hold VA: 4.5 VA - Net Weight: 0.39 kg - Dimensions: Width 3.54 in; Overall Height 2.28 in; Overall Depth 2.24 in - Impulse Withstand Voltage: 8 kV - Standards: BS 5424, CSA, IEC 60947, NF C 63-110, UKCA, UL Listed, VDE 0660 - Enclosure: No Enclosure; IP20
