IEC Miniature Magnetic Contactor, 1NO, 24V DC, 3 P, Non-Reversing, Screw Clamp LP1K1210BD

The SQUARE D IEC Miniature Magnetic Contactor is a TeSys K, 3-pole, non-reversing IEC contactor with a 24 V DC coil. It contains three main normally open contacts and one auxiliary contact as specified, suitable for use with motors and resistive loads within specified parameters. Its compact form supports installation in space-constrained control panels on DIN rails or plates. - Coil voltage: 24 V DC - Action: Non-Reversing - Poles/Contacts: 3P; main contacts 3 NO; auxiliary contact 1 NO - Mounting: DIN Rail, Plate - Frame/Series: TeSys K - Maximum voltage: Power circuit up to 690 V AC; Signalling circuit up to 690 V AC - Frequency: 50/60 Hz - Ambient operating/storage: -25 to 50 °C (operation); -50 to 80 °C (storage) - Enclosure/IP: Enclosure rating is IP2X; no additional enclosure provided - Rated making capacity: 144 A (AC Power Circuit); 110 A (AC Signalling Circuit) - Full load current: Full load current ratings are based on specified conditions - Durability: Durability ratings are based on testing under standard conditions - Terminal: Screw Clamp - Net weight: 0.225 kg - Dimensions (W x H x D approx): 1.77 in x 2.28 in x 2.24 in - Operating speed: 3600 cycles per hour - Operating time: 30–40 ms (coil energisation and NO closing); 10 ms (coil de-energisation and NO opening)
