IEC Miniature Magnetic Contactor, 1NC, 24V DC, 3 P, Reversing, Screw Clamp LP2K1201BD

The IEC Miniature Magnetic Contactor is a compact, electrically operated switching device used to control low-power circuits. It employs a 24 V DC coil to open and close contacts and provides reversing action for motor direction control. The unit has 3 poles and 1 NC auxiliary contact; it uses screw clamp terminals and can be mounted on a DIN rail or plate with no enclosure. It is rated for operation within the specified voltage and frequency ranges and features IP20 protection, with an operating temperature range from -13°F to 122°F. - Coil voltage: 24 V DC - Poles: 3 - Reversing: Yes - Auxiliary contacts: 1NC - Auxiliary contact form: 1NC - Electrical connection: Screw Clamp Terminals - Mounting style: DIN Rail, Plate - Enclosure: No Enclosure; IP20 - Rated voltage: 690 V AC; Frequency: 50/60 Hz - Net weight: 0.48 kg - Series: TeSys K - Fuse amps: 25 A (Power Circuit); 10 A (Signalling Circuit) - Rated making capacity: 110 A (AC Signalling); 144 A (AC Power) - Mechanical durability: 5 Mcycles - Electrical operating durability: 1,300,000 cycles
