IEC Miniature Magnetic Contactor, 1NC, 24V DC, 3 P, Non-Reversing, Screw XTMC9A01TD

The Eaton XT IEC mini contactor is an IEC miniature magnetic contactor with 3 poles and a 24 V DC coil. The contactor is rated for non-reversing operation within its specified design parameters. The device features screw terminals and supports DIN Rail or Panel mounting options; it does not include an enclosure. - Action: Rated for non-reversing operation within specified conditions. - Coil Voltage: Rated coil voltage: 24 V DC (within manufacturer specifications). - Poles / Contact Configuration: Configured with 3 poles and one normally closed auxiliary contact (1NC). - Auxiliary Contacts: Contains one auxiliary contact of form 1NC, as specified by the manufacturer. - Amperage Rating / Full Load: Rated for full load currents up to these values under standard testing conditions. - Maximum Voltage Rating: Suitable for applications up to a maximum voltage of approximately this value, per ratings listed in specifications. - Frequency: Designed to operate at standard power frequencies of either 50 Hz or 60 Hz within rated conditions. - IP Rating: Has an ingress protection rating of IP20, indicating limited dust protection but no water resistance. - Enclosure: Does not include an enclosure; suitable for installation in appropriate enclosures or panels according to standards. - Mounting Style / Position: Supports DIN Rail or panel mounting configurations in vertical orientation as per installation guidelines. - Electrical Connection: Screw - Embedded Surge Suppressor: Yes - Frame / Series: XT; Frame Size: A - Certifications: UL Listed; CSA Certified; CE Marked; EN 60947; IEC 60947; RoHS - Dimensions: Width 1.44 in; Height 2.28 in; Depth 1.79 in - Operating Temperature: -13°F to 122°F - Mechanical Durability: 20,000,000 cycles - Item / Product Name: IEC Miniature Magnetic Contactor; Eaton XT IEC mini contactor
