Ham-Let H-480OP-SS-N-1-4-1-3PSI

The HAM-LET H-480OP-SS-N-1/4-1/3PSI is an instrumentation check valve for use in one-way flow applications in compatible small-bore liquid or gas lines. It uses an inline spring, poppet-style mechanism for reverse-flow checking in compatible instrumentation and process systems; verify media compatibility with listed materials. The one-piece inline body has 1/4 in male NPT connections on both ends for compatible 1/4 in female NPT connections. Key Features: Valve type: Instrumentation check valve with 2-way inline body design Connection style: 1/4 in MNPT x MNPT Body material: 316 stainless steel Check mechanism: Poppet with 316 stainless steel check mechanism and 302 stainless steel spring Seal and seat materials: FKM seal and 316 stainless steel seat Cracking pressure: 0.33 psi Flow capacity: Cv 0.35 Pressure rating: 3,000 psi maximum operating pressure Temperature range: -10 degrees F to 375 degrees F Mounting orientation: Horizontal or vertical Overall length: 1.61 in Hex size: 9/16 in Standards: C.R.N 0C16552.2
