Campbell 1-1-4" FNPT Lead Free Brass Spring Check Valve 4062EVFD

The CAMPBELL 4062EVFD is a 1-1/4 in. check valve with an inline spring design. It is intended for one-direction water flow applications and reverse-flow checking in piping and pump systems. This general-purpose valve features a lead-free brass body, FNPT x FNPT connections, and a 0.5 psi cracking pressure. Key Features: Nominal size: 1-1/4 in. Connection type: FNPT x FNPT; female NPT on both sides Body material: Lead-free brass Mechanism: Poppet with inline spring body design Check mechanism and spring material: 302 stainless steel Seal material: Buna-N Seat material: Bronze For media: Water Flow capacity: 23 gpm Maximum pressure: 400 psi Operating temperature range: 35 degrees F to 180 degrees F Mounting orientation: Horizontal, vertical NSF certification: NSF 61 Standard: ANSI B1.20.1 Overall length: 4.59 in.; overall height: 2-1/4 in.
