Edwards Signaling 871P-G1

EDWARDS SIGNALING 871P-G1 is a vibrating horn for audible warning applications. It operates on 24V DC and produces a continuous horn signal with selectable volume, rated at 78 to 91 dB, with a maximum output of 101 dB at 1 m and 91 dB at 10 ft. The unit is housed in gray die-cast material and is configured for surface mounting; for indoor or outdoor locations. Key Features: Audible alarm type: Horn Sound style: Horn Sound pattern: Continuous Number of sound patterns: 1 Sound principle: Vibrating Vibration: Vibrating Input/operating voltage: 24V DC Current draw: 0.16 A Alarm volume: 78 to 91 dB Maximum output: 101 dB at 1 m Maximum output: 91 dB at 10 ft Mounting style: Surface mount Connection type: Plug-in assembly Power source: Wire Housing/material: Die-cast housing with finish Color: Gray Rating: NEMA 4X For location: Indoor, outdoor Includes: Enclosure, gasket Overall size: 4 5/8 in. H x 4 5/8 in. W x 1 7/8 in. D Visual indicator type: None Standards: UL Listed
