Parker Quick Connect Plug, Lincoln, 1-4 in Body, 1-4 in FNPT, Steel, 300 psi L3C

The PARKER - L3C is a quick connect hose coupling intended for pneumatic service. It supports tool-free connection and disconnection using the sleeve locking mechanism. Constructed from steel with a trivalent chrome finish, it provides a sealed connection (per specified seal material: Nitrile) for compatible pneumatic couplings. The coupling is compatible with 1/4-inch NPT threaded connections and female hose fittings, supporting a maximum working pressure of 300 psi and a maximum flow rate of 707.92 liters per minute. Its operating temperature range spans from -40°F to 250°F, with a maximum outside diameter is 11/16 in and overall length is 2.13 in. Key Features: - Application: Pneumatic service - Body size and coupling size: 1/4 in - Connection type: 1/4" -18 NPT thread - Coupling component: Plug with sleeve locking type - Hose fitting gender and size: Female, 1/4 in - Material: Steel with trivalent chrome finish - Seal material: Nitrile - Max. working pressure at 70°F: 300 psi - Max. flow rate: 707.92 lpm - Temperature range: -40°F to 250°F - Max. outside diameter: 11/16 in - Overall length: 2 1/8 in - Includes valve: No - Interchange type: Lincoln
