Hubbell Wiring Device-Kellems HBL330P6W

The HUBBELL IEC Pin and Sleeve Plug is a watertight electrical connector suitable for industrial and commercial environments. This plug features a 2-pole, 3-wire configuration, rated for 30A and 250V AC single-phase power. Constructed with a rugged Zytel 801 nylon body and non-metallic housing, it features impact- and moisture- construction. The device includes grounded connections using the IEC grounding style and accommodates wire sizes from 12 AWG to 8 AWG.Key Features of the HUBBELL IEC Pin & Sleeve Plug: Current/Voltage Rating: Rated for 30 amps at 250V AC single phaseWatertight Construction: Gasketed sealing ring with IP67 rating; NEMA Type 4X enclosureMaterial: Body made from Zytel 801 nylon; non-metallic housingCable Accommodation: Accepts cable diameters from 0.5 in to 1.25 inTemperature Range: Operates between -40°C to +75°CWire Connection Type: Screw terminals support wire sizes from #12 AWG (min) to #8 AWG (max)Pins & Wires: Two poles, three wires; shrouded designStandards Compliance: CSA Certified C22.2 No.182.1; UL E146032; UL IEC60309-1 listedResistance Properties: Impact , moisture , watertight construction
