Dayton Air Chain Hoist, 2000 lb. Cap., 20 ft. Lift 29XL89

The Dayton 29XL89 is an air-powered chain hoist designed for industrial lifting and lowering operations in environments. Performance and Lifting Specifications: - Load Capacity: Features a primary load capacity of 2,000 lbs, with a maximum pulling capacity of 2,500 lbs. - Lift and Speed: Provides a maximum lifting length of 20 feet at a fixed lift speed of 23 feet per minute (fpm). - Chain Configuration: Utilizes two reeves and two Grade 80 alloy steel load chains for stable lifting. - Braking System: Equipped with both disc and shoe-type brakes to ensure secure load holding. Pneumatic Requirements: - Air Pressure: Operates at a standard air pressure of 90 psi. - Air Consumption: Requires a constant air flow of 48 scfm during operation. - Inlet Details: Features a 3/8-inch NPT female air inlet. Construction and Design: - Body Material: Built with a cast aluminum housing finished in red paint. - Hook Type: Includes top and bottom swivel latch hooks made of alloy steel, featuring safety latches and a 1 1/16-inch opening width. - Control Type: Operated via a pendant throttle. - Headroom: Requires 18 inches of headroom (minimum distance between hooks) for proper installation.
