Gast Piston Air Compressor,Size 1-4",1725 RPM 1HAB-11T-M100X

The Gast 1HAB-11T-M100X is an oil-free, single-cylinder piston air compressor with a reciprocating design. It operates on 115V AC single-phase power at 60 Hz at a rated 0.12 hp output. The oil-free design means the compression chamber runs without lubricant. It provides a free-air flow rate of 1.3 cfm, and a maximum continuous pressure of 100 psi. It has a maximum speed of 1,725 RPM, a full-load current of 3.8 A, and a measured sound level of 70 dBA. The operating temperature range is 32 to 104°F. Construction includes an aluminum cylinder, an induction motor, and stainless steel valves. Enclosure type is clean dust free. Air connections are 1/4 in NPT inlet and outlet. Overall dimensions are 17.53 x 8.3 x 16.66 in (L x W x H). Duty cycle: continuous. Rated life expectancy: 16,000 hr.
