Asco EF8262H226V

The ASCO EF8262H226V is a 2-way, 2-position, normally closed solenoid valve featuring direct-acting operation; flow characteristics are not specified. It is constructed with a stainless steel body and FKM seals, designed to handle fluids such as air, inert gases, light oil, and water. The valve operates on 120V AC at 60 Hz with a wattage of 10.1 W, and includes the coil and sealing components necessary for installation. It supports both horizontal and vertical mounting orientations. The valve’s operation is controlled by a watertight coil enclosure with Class F insulation. Key Features: - Nominal Pipe Size: 1/4 in with NPTF inlet and outlet connections - Center Line Pipe Center Size: 2-13/16 in - Orifice Diameter: 7/32 in - Maximum Ambient Temperature: 131°F; Minimum Ambient Temperature: -13°F - Maximum Fluid Temperature: 180°F - Maximum Operating Pressure Differential: 100 psi (Air/Inert Gas, Fuel Oil, Light Oil, Water) - Minimum Operating Pressure Differential: 0 psi (Air/Inert Gas, Fuel Oil) - Response Time: 1 second - Overall Dimensions: Length 1-9/16 in, Width 1-15/16 in, Height 3-1/8 in - Electrical Connections: 1/2 in Conduit with 18 in Leads - Valve Starting Configuration: Normally Closed - Includes: Coil and Seals - Certifications: CE, CSA, FM, UL Listed
