Parker 1-4" CPI(R) Stainless Steel Instrumentation Check Valve 4Z-C4L-10-SS

PARKER 4Z-C4L-10-SS is a 1/4 in instrumentation check valve for one-way flow control in small-bore fluid and gas lines. This inline poppet valve uses compression x compression CPI(R) connections and a 316 stainless steel body. It is intended for one-way flow control in instrument and process systems. Key Features: Instrumentation check valve with inline poppet mechanism and single-flow design 1/4 in nominal valve size with 1/4 in connections on both sides Compression x compression CPI(R) connections 316 stainless steel body FKM / fluorocarbon seal and seat material 316 stainless steel spring 10 psi cracking pressure Cv 0.75; flow rating 0.75 gpm 6,000 psi maximum operating pressure; 6,000 psi CWP; 6,000 psi maximum water pressure at 100 Degrees F Temperature range: -15 Degrees F to 400 Degrees F Horizontal or vertical mounting orientation 2.42 in overall length; 3/4 in hex size ASTM A 276
