Swing Check Valve, Inline, 2 in, FNPT x FNPT, PVC Body, 6-3-16 in Overall L 1520-20F

NDS swing check valve with an inline body design for water service. The swing check mechanism uses a flapper-style design to allow one-direction flow and reduce reverse flow. It features a PVC body, PVC seat, and EPDM seal, with 2 in. female threaded connections. Key Features: Valve type: Swing check valve with inline body design Material: PVC body and PVC seat with EPDM seal Connection size: 2 in. on both sides Connection type: FNPT x FNPT, female x female Media: Water Flow rate: 78.44 gpm Cracking pressure: 0.25 psi Full flow: Yes Pressure ratings: 125 psi at 72 degrees F maximum pressure; 150 psi at 70 degrees F maximum water pressure Temperature range: 14 degrees F minimum to 140 degrees F maximum Mounting orientation: Horizontal or vertical Certifications/standards: NSF 61 Overall length: 6.14 in. Overall height/width: 4 19/64 in.
