Bonomi 3-4" Sweat Brass Spring Check Valve 100712LF-3-4"

BONOMI 100712LF-3/4 is a 3/4 in. inline spring check valve with sweat x sweat connections and a lead-free brass body. It is intended for compatible gas, oil, and water line applications requiring one-way flow and reverse-flow reduction. The valve features a swing check mechanism, a full-flow design, and a 0.5 psi cracking pressure. Key Features: Nominal size: 3/4 in. Connection type: Sweat x sweat; female connections on both sides Body material: Lead-free brass Valve type: Inline spring check valve with swing check mechanism Flow capacity: 16.3 gpm; Cv: 14.1 Pressure ratings: 400 psi WOG maximum pressure; 200 psi maximum water pressure Operating temperature range: -4 F to 210 F Seat material: Buna-N / NBR; seal materials: Buna-N and Spring material: 302 stainless steel; check mechanism material: PPS Mounting orientation: Horizontal or vertical Standards and listings: NSF 61, ANSI B16.18, NSF 372, UL Listed Dimensions: 4.17 in. overall length, 1-21/32 in. overall height, 1.65 in. width
