Asco EF8210G056

The ASCO EF8210G056 is a pilot-operated, normally closed solenoid valve designed for controlling the flow of air, inert gas, light oil, and water. It offers automated on/off control through an energized coil that moves the valve plunger to open or close the flow path. This valve features a 1-1/2 inch nominal pipe size with NPTF inlet and outlet connections and a 1-1/4 inch orifice diameter, accommodating flow with a coefficient of volume (Cv) of 22.5. Ambient temperature range 14°F to 140°F and fluid temperatures up to 180°F. Key Features: - Valve Design: 2-Way/2-Position, Normally Closed configuration - Valve Type: High Flow with pilot-operated actuation - Material: Brass valve body with NBR seal material - Electrical: 120V AC, 60 Hz coil included, 16.1 W wattage, Class F coil insulation - Coil enclosure: explosion-proof and watertight; electrical connection: 1/2 in conduit hub - Environmental Rating: Indoor and Outdoor use - Operating Pressure Differential: 0 to 150 psi for Air/Inert Gas; 0 to 125 psi for Light Oil and Water - Temperature Ratings: Ambient temperature - minimum 14°F to maximum 140°F; fluid temperature up to 180°F - Dimensions: Overall length 4-3/8 in, width 3-15/16 in, height 6 in; center line pipe center size 4-13/16 in - Mounting Orientation: Vertical installation recommended - Response Time: 1 second - Compliance: UL Listed standard
