Asco 8210G094LF 240-60, 220-50

The ASCO 8210G094LF is a pilot operated, normally closed solenoid valve designed for controlling the flow of air, inert gases, light oil, and water. Featuring a 2-way/2-position high flow design with a 5/8 inch orifice diameter. It provides automated flow control with a response time of approximately 1 second and is intended for vertical mounting orientation. The valve operates on 220V or 240V AC power at frequencies of 50 Hz and 60 Hz. Key Features: - Valve Design: 2-Way/2-Position, Normally Closed, High Flow - Orifice Diameter: 5/8 in - Nominal Pipe Size: 1/2 in with NPTF inlet and outlet connections - Operating Pressure Differential: 0 to 150 psi for air, inert gases, and water - Maximum Fluid Temperature: 180°F - Body Material: Brass - Seal Material: NBR - Coil: Included, Class F insulation, 10.1 W power consumption - Coil Enclosure: Watertight, with 1/2 in conduit hub electrical connection - Environmental Rating: Indoor and Outdoor use, NEMA ratings 1, 2, 3, 3S, 4, and 4X - Compliance: CSA and UL standards - Dimensions: Overall Length 2-5/16 in; Width 2-3/4 in; Height 3-27/32 in - Ambient Temperature Range: 14°F to 140°F - IP Rating: 65 - Includes Seal components
