90° Elbow, 316 Stainless Steel, 3-8 in FNPT x FNPT, 5,000 psi Max Pressure 6-6 FE-SS

The PARKER - 6-6 FE-SS is a 90 Degree Elbow stainless steel pipe fitting made of 316 stainless steel, manufactured to provide a 90° change in flow direction within specified parameters. It features female National Pipe Thread (NPT) connections on both ends with a nominal pipe size of 3/8 inch. This fitting is suitable for conveying air, natural gas, and oil in various piping systems. It is rated for operation at pressures up to 5,000 psi within specified conditions and can function within a temperature range of -425 to 1200 degrees Fahrenheit. The fitting meets the requirements of ANSI B31.1, ANSI B31.3, and ANSI B1.20.1 standards. Key Features: - Pipe fitting material: 316 Stainless Steel - Connection type: Female NPT x Female NPT - Nominal pipe size: 3/8 inch on both ends - Thread size: 3/8-18 - Rated for operation at pressures up to 5,000 psi within specified conditions - Rated for operation within a temperature range of -425 to 1200 °F - Hex wrench size: 7/8 inch - Overall length: 2 inches - Intended for use with air, natural gas, and oil in accordance with applicable standards - No pre-applied thread sealant or included seal - Color: Silver
