Manufacturer Varies 1" FNPT 304-304L SS 90 Degree Elbow 2000300112

The ZORO SELECT 2000300112 is a 90 Degree Elbow made from stainless steel, designed to connect two pipes at a right angle to facilitate a change in flow direction. Compatibility with specific fluids is not specified; rated for corrosion resistance and a Class 3000 pressure rating, with verification per applicable codes. Maximum rated pressure: 3,000 psi (Class 3000); maximum operating pressure at 100°F is 2,570 psi. It is constructed from 304/304L stainless steel for durability and corrosion resistance. Finish: Electro-polished surface providing corrosion resistance. Key Features: - Material: 304/304L Stainless Steel for corrosion resistance and durability - Fitting Shape: Elbow with a 90-degree angle for directional change - Connection Type: FNPT end connections for threaded pipe joints - Maximum rated pressure: 3,000 psi (Class 3000) - Maximum operating pressure at 100°F: 2,570 psi - Finish: Electro-polished surface providing corrosion resistance - Ends: Fitting Side A and B both Female, with nominal size of 1 inch and outside diameter of 2 3/16 inches - Threading: Side A and B both have 11 1/2 TPI threaded ends - Standards: Conforms to ASTM A182/ASME SA182, ASME B16.11, ANSI B1.20.1
