Dixon Coupler, Brass, 1-4 FNPT, 1-4 Body 2FF2-B

The DIXON - 2FF2-B is a quick connect hose coupling configured for connection and disconnection without additional tools (socket-and-sleeve coupling design) at the end of a hose or pipe. It features a female hose fitting with a 1/4 inch size and a 1/4 inch NPT threaded connection type. Constructed from brass with a zinc-plated finish, this coupling is suitable for fluid and air lines, intended to form a sealed connection for fluid/air lines under the specified working pressure and temperature conditions. The coupling includes an integral tubular valve for controlling flow and operates with a sleeve locking mechanism. The coupling is rated for a maximum working pressure of 500 psi at 70°F and a maximum flow rate of 764.55 liters per minute, with operational temperatures ranging from -40°F to 250°F. Key Features: - Application: On end of hose or pipe - Hose fitting gender: Female - Hose fitting size: 1/4 in - Connection type: NPT - Coupling component: Socket - Coupling locking type: Sleeve - Coupling size: 1/4 in - Includes valve: Yes, tubular type - Material: Brass - Finish/coating: Zinc plated - Seal material: Nitrile - Max. working pressure: 500 psi @ 70°F - Max. flow rate: 764.55 lpm - Overall length: 2.06 in (2 1/16 in) - Max. outside diameter: 15/16 in - Temperature range: -40°F to 250°F - Thread size: 1/4"-18 - Interchange type: Industrial
