Reelcraft HD76100 OLP

The REELCRAFT HD76100 OLP is a spring return hose reel for air or water service, supplied with a 3/8 in. I.D. x 100 ft PVC hose. It has a stationary steel reel with a powder-coated finish and can be mounted on a bench or truck, or to a ceiling, floor, or wall. The reel uses a spring-loaded locking latch and includes a hose stop and bumper. Key features of the REELCRAFT HD76100 OLP: Spring return drive: Rewinds the hose onto the reel after use. 100 ft hose included: Comes with a red PVC hose sized 3/8 in. I.D. for air or water service only. 300 psi maximum pressure: Rated for operating pressures up to 300 psi. 32 to 150 degrees F operating range: Suitable for use within the listed temperature limits. Steel construction: Carbon steel reel with all-steel frame components. Powder-coated finish: Helps resist corrosion on the reel exterior. Ball bearing design: Permanently lubricated ball bearings support smoother spool rotation. Adjustable guide arm: Single guide arm can be set in seven positions. 1/2 in. NPT connections: Reel inlet is 1/2 in. FNPT with 1/2 in. NPT male hose ends. Open reel design: Non-enclosed reel with single pedestal base. Mounting pattern: Four 1/2 in. mounting holes with 7 13/16 in. x 3 7/8 in. center-to-center spacing. Overall size: Measures 19 3/4 in. L x 8 1/4 in. W x 20 1/4 in. H.
