Aignep Usa Safety Exhaust Coupler,1-4",Brass 80622-04

The AIGNEP USA - 80622-04 is a hose coupling for pneumatic applications with quick-connect feature. Rated for pneumatic use (within specified pressure/temperature ranges), it provides rapid connection and disconnection without requiring tools (per product design) using an integrated safety vent locking mechanism. Constructed of brass with a zinc black anodized finish, the coupling includes an integrated poppet valve and features a socket component. It has a maximum flow rate of 595 L/min. It supports a maximum working pressure of up to 220 psi at 70°F, with a temperature range from 0°F to 180°F. The coupling provides a connection intended to be sealed using the included nitrile seal (compatibility based on specified installation/conditions) and is compatible with specified industrial interchange standards (as applicable). Key Features: - Application: Pneumatic use. - Connection type: 1/4" NPT female thread. - Coupling size and hose fitting size: 1/4 in. - Hose fitting gender: Female. - Coupling component: Socket. - Coupling locking type: Safety Vent. - Material: Brass with zinc black anodized finish. - Seal material: Nitrile. - Includes integrated poppet valve. - Maximum flow rate: 595 lpm. - Maximum working pressure: 220 psi @ 70°F. - Maximum outside diameter: 1 3/16 in. - Overall length: 2 3/16 in.
