Parker 1-2" A-LOK(R) Stainless Steel Instrumentation Check Valve 8A-C8L-10-SS

PARKER 8A-C8L-10-SS is a 1/2 in instrumentation check valve for one-way flow control in small-bore fluid and gas lines. This inline poppet valve uses A-LOK® compression x compression connections, is constructed with a 316 stainless steel body and 316 stainless steel spring, and provides check-valve function for reverse-flow control in instrument and process systems. Key Features: 1/2 in nominal valve size with 1/2 in compression connections on both ends Inline poppet mechanism with single-flow design 316 stainless steel body and 316 stainless steel spring For fluids and gas media 10 psi cracking pressure 3.3 gpm flow capacity with Cv of 3.3 Maximum operating pressure: 6,000 psi; maximum water pressure: 6,000 psi at 100°F Operating temperature range: -15°F to 400°F FKM/fluorocarbon seal material FKM/fluorocarbon seat material Horizontal or vertical mounting orientation 4.08 in overall length; 1 1/4 in hex size ASTM A276 standard
