Hubbell Wiring Device-Kellems HBL29W77

The HUBBELL 30A Watertight Locking Connector (L17-30R) is a three-pole, four-wire connector designed for industrial and commercial electrical applications intended for use in environments where watertight protection is specified. Constructed with a smooth elastomer body and corrosion- components, this connector features a smooth body design. It is rated for 600VAC operation and meets NEMA WD-1, WD-6, ANSI standards, as well as multiple enclosure ratings including NEMA 4, 4X, 6, 6P and IP69K.Key Features of the HUBBELL - 30A Watertight Locking Connector: Current/Voltage Rating: Rated for up to 30 amps and 600V ACNEMA Configuration: L17-30R; three poles/four wires; groundedBody Material: elastomer housing with Valox construction for durabilityCord Accommodation: Accepts cord diameters from 0.375 in to 1.125 inOperating Temperature Range: -40°C to +60°C continuous useResistance Properties: Constructed from materials listed as , moisture (UL Listed), and UV stabilizedConnection Type: Screw terminals with nickel-plated brass contactsNEMA & IP Ratings: Meets the following enclosure ratings: NEMA Types 12, 4, 4X, 6; IP69KStrain Relief Nut Design: Strain relief nut designed to fit securely on the connector body
