Hubbell Wiring Device-Kellems HBL5969VGY

The HUBBELL 5-15R Straight Blade Connector is an electrical connector intended for use in industrial and commercial settings. It features a hinged, one-piece elastomer body to facilitate assembly and maintenance. This connector accommodates #18 AWG to #12 AWG stranded copper wire and supports cord diameters from 0.220" to 0.660". Rated for 15A at 125V AC, it includes screw terminal wiring for grounded connections.Key Features of the HUBBELL 5-15R Straight Blade Connector: Amperage/Voltage Rating: Rated for 15 A, 125 V AC operationNEMA Configuration: NEMA 5-15R receptacle configurationWire Accommodation: Accepts #18 AWG to #12 AWG stranded copper wireCord Range: Suitable for cords with diameters between 0.220" and 0.660"Body Design: Hinged one-piece construction facilitates assembly; captive screws are included for convenience during wiringCord Grips: Offsetting cord grips are used on individual conductorsMaterial Construction: elastomer housing with brass contacts; nylon components includedGrounding Style: Grounded design enhances connection reliabilityOperating Temperature Range: -40°C (without impact) up to +75°C continuous useStandards Compliance: CSA Certified, UL Listed, NEMA WD-6 compliant
