IEC Miniature Magnetic Contactor, 1NC, 24V AC, 3 P, Reversing, Screw Clamp LC2K0601B7

The item is an IEC miniature magnetic contactor (Schneider Electric, TeSys K series). It is a 3-pole reversing contactor with a 24 V AC coil and 1 NC auxiliary contact, suitable for use in motor control applications within specified parameters. Key features - Function: Reversing (further details should be provided separately) - Application: designed for motor control applications within specified electrical ratings - Coil Voltage: 24 V AC - Poles / Main contacts: 3 poles; 3 normally open main contacts - Auxiliary contacts: 1 NC - Auxiliary contact configuration: 1NC - Electrical connection: Screw Clamp Terminals - Mounting: DIN Rail, Plate (Mounts On: Plate, Rail) - Series: TeSys K - Enclosure: open device; appropriate enclosure should be used as per installation requirements - IP Rating: IP20 - Standards: BS 5424, CSA, IEC 60947, NF C 63-110, UKCA, UL Listed, VDE 0660 - Fire rating: fire ratings are based on testing standards; actual performance depends on application conditions - Rated Voltage: rated for operation up to 690 V AC within specified conditions - Frequency: 50/60 Hz - Net Weight: 0.39 kg - Dimensions (W x H x D): 3.54 in x 2.28 in x 2.24 in - Environmental: environmental certifications are based on testing and compliance standards; actual safety depends on proper usage and handling - Electrical durability: 1.3 Mcycles - Mechanical durability: 5 Mcycles - Rated Make Capacity: 110 A - Full Load Amps: Inductive 6 A; Resistive 15 A - Impedance: 3 mΩ - Impulse withstand voltage: 8 kV - Rated insulation volts: 600/690 V - Max operating voltage: 690 V Specifications recap - Series: TeSys K - Coil Voltage: 24 V AC - Poles / Main contacts: 3 poles; 3 normally open main contacts - Auxiliary contacts: 1 NC - Electrical connection: Screw Clamp Terminals - Mounting: DIN Rail, Plate - Enclosure: open device; appropriate enclosure should be used as per installation requirements - IP Rating: IP20 - Rated Make Capacity: 110 A - Full Load Amps: Inductive 6 A; Resisti
