IEC Miniature Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing, Screw Clamp LC1K1210B7

The SQUARE D IEC Miniature Magnetic Contactor is a 3-pole, non-reversing device with a 24 V AC coil. It is rated for switching applications within specified load types, and it features one normally-open auxiliary contact with screw clamp terminals. The unit is suitable for DIN rail or panel mounting as per installation guidelines and is provided without an enclosure; compatible with environments requiring IP22-rated enclosures. - Coil voltage: 24 V AC - Poles/Main contacts and aux: 3 poles; 3 normally open main contacts; 1 NO auxiliary contact - Reversing: Non-Reversing - Application: Motor control, resistive load - Maximum voltage: 690 V AC - Full Load Amps: 20 A (resistive), 12 A (inductive) - Mounting/Terminals: DIN rail or plate mounting; Screw Clamp terminals - Durability: Mechanical 10 Mcycles; Electrical 1,300,000 cycles - Enclosure/IP: Provided without an enclosure; compatible with environments requiring IP22-rated enclosures - Physical size: 1.77 in W × 2.28 in H × 2.24 in D; weight 0.18 kg - Series: TeSys K - Operating time: 10–20 ms
