IEC Miniature Magnetic Contactor, 1NO, 240V AC, 3 P, Non-Reversing, Screw Clamp LC1K1210U7

The IEC Miniature Magnetic Contactor is a 3-pole, non-reversing device with 1 normally open auxiliary contact (1NO) and a 240 V AC coil. It is rated for operation with motor control and resistive loads within specified parameters and uses screw clamp terminals. Its IEC-style construction is compatible with mounting on DIN rails or plates as specified. - Series: TeSys K; Contactor Style: IEC; Action: Non-Reversing; Application: Motor Control, Resistive Load - Coil Voltage: 240 V AC - Poles / Main Contacts: 3 poles; 3 NO main contacts - Auxiliary Contacts: Includes 1 auxiliary contact (1NO); Auxiliary Form: 1NO - Electrical Connection: Screw Clamp Terminals - Enclosure: No Enclosure; IP Rating: IP22 - Mounting: DIN Rail, Plate; Mounts On: Plate, Rail - Rated Voltage: rated for operation at voltages up to 690 V AC within the specified voltage range - Net Weight: 0.18 kg - Dimensions (Overall): 2.24 in D x 2.28 in H x 1.77 in W - Mechanical Durability: tested for mechanical durability up to 10 million cycles under standard conditions - Electrical Durability: electrical durability ratings based on standardized testing conditions; actual performance may vary depending on application specifics - Hold VA: 4.5 VA; Inrush VA: 30 VA - Embedded Surge Suppressor: No - Includes Auxiliary Contacts: Yes - Impedance: 3 mΩ - Fire Rating: complies with fire safety standards UL 94 V1 and relevant NF standards when tested according to their procedures - Impulse Withstand Voltage: rated to withstand impulse voltages up to specified levels under test conditions
