IEC Magnetic Contactor, 1NC-1NO, 24V DC, 3 P, Non-Reversing, Screw Clamp LC1D09BL

The Schneider Electric IEC Magnetic Contactor is a three-pole, non-reversing magnetic switch (IEC style) with a 24 V DC coil. It is designed to control motor control and resistive load circuits and uses screw clamp terminals. The unit includes two auxiliary contacts (1NO/1NC) and is part of the TeSys Deca series. It is rated for operation within the specified voltage ranges, designed to operate within standard frequency ranges, and has an IP20 rating; suitable for indoor use in protected environments. Mounting options include DIN Rail or Plate, with mounting on Plate or Rail. Key features - Coil Voltage: 24 V DC - Poles / Main Contacts: 3 poles; 3 normally open main contacts - Auxiliary Contacts: 2 total (1NO/1NC) - Reversing: Non-Reversing - Frame / Series: TeSys Deca; Contactor Style: IEC - Electrical connections: Screw Clamp Terminals - Ratings: 690V AC / 300V DC; Frequency 50/60 Hz - Currents (Full Load): Resistive 25 A; Inductive 9 A - Protection / Enclosure: IP20; No Enclosure; Protective Cover Included; Embedded surge suppressor (bi-directional diode) - Weight / Dimensions: 0.48 kg; depth 3.74 in; height 3.03 in; width 1.77 in - Standards: EN 60947-4-1, EN 60947-5-1, UL 508, UL Listed, and others listed - Other: Reversing capability No; Series TeSys; Series name included in description - Overvoltage category: CAT III - Fire rating: UL 94 V1 - Working mounting: DIN Rail, Plate (Mounts on Plate, Rail)
