IEC Magnetic Contactor, 1NC, 24V DC, 3 P, Non-Reversing, Screw XTCE015B01TD

The Eaton XT IEC contactor is a 3-pole, non-reversing IEC magnetic contactor with a 24 V DC coil. It includes one auxiliary contact (1NC) and uses screw terminals for wiring. It is part of the XT series with Frame B. Key features: - Coil Voltage: 24 V DC - Action / Reversing: Non-Reversing - Poles: 3 - Contact Configuration: 1 NC - Aux Contacts: Includes 1 auxiliary contact (1NC) - Maximum Voltage Rating: 690 V AC - Full Load Amps: Inductive 15 A; Resistive 22 A - Electrical Operating Durability: 1,200,000 cycles (based on testing standards) - Mechanical Operating Durability: 10,000,000 cycles (based on testing standards) - Mounting Style: DIN Rail, Panel - Terminals: Screw - Frame/Series: XT, Frame B - Enclosure: No Enclosure; IP20 - Certifications/Standards: UL Listed; CSA Certified; IEC 60947; EN 60947; CE Marked; RoHS - Response Time: DC opening <12 ms; AC opening <18 ms; AC closing <21 ms - Includes Auxiliary Contacts: Yes - Frame Size: B
