IEC Magnetic Contactor, No Auxiliary Contacts, 24V AC, 4 P, Non-Reversing 6EAY2

The DAYTON - IEC Magnetic Contactor is a non-reversing, 4-pole device with no auxiliary contacts. It operates on a coil voltage of 24V AC and has a frequency of 50/60 Hz. This contactor is designed to handle full load amps-inductive of 12 A and full load amps-resistive of 25 A. The compact design measures an overall depth, height, and width each at 1.77 inches. Key features include: - Non-reversing action: This means the contactor does not have the capability to reverse its direction. - No Auxiliary Contacts: There are no additional contacts for supplementary functions. - Coil Voltage: Operates on a standard electrical current of 24V AC. - Full Load Amps: Rated for inductive loads of 12A and resistive loads of 25A. - Compact Size: With dimensions all measuring at approximately less than two inches, it can fit into tight spaces easily. - Horsepower Ratings: Compatible with devices having horsepower ratings within the range of one hp @ single phase -120V AC to two hp @ single phase -240V AC. - Main Contact Configuration: Features special main contact configuration with two normally closed (2NC) and two normally open (2NO) main contacts. -Standards Compliance: Complies with CSA and UL Listed standards as per North American safety regulations.
