Miniature Limit Switch - 914CE, SPDT, Side Rotary Head, 6 ft Cable, NEMA Rated 914CE16-6

For use in North America, the Honeywell 914CE Series Limit Switch is a compact, enclosed rotary switch suitable for a variety of applications. This model features a side-mounted rotary actuator head without a lever and includes SPDT (1NC/1NO) contacts rated at 5A, 240V AC. The switch body is constructed from die-cast zinc with a miniature form factor and includes a pre-wired 6 ft cable for electrical connection. It is constructed to comply with specified NEMA enclosure ratings and ingress protection standards. Key Features: - Contact Rating: 5A at 240V AC (SPDT: 1NC/1NO) - Actuator Style: Side rotary head without lever; spring return action - Body Construction: Miniature die-cast zinc housing - Electrical Connection: Pre-wired with a 6 ft SJTO cable - Mounting: Surface mount with two horizontal holes (0.2 in diameter; spaced at 0.98 in center-to-center) - Movement & Travel: Operates CW or CCW; differential travel of 3°, pretravel of 30°, overtravel of 40° - Environmental Ratings: NEMA types 1,2,3,3R,4,6,6P &13; IP66/IP67/IP68 - Operating Temperature Range: From 35°F to160°F (2°C to71°C) - Standards Met: CE marked; CSA certified; IEC947-5-1; EN60947-5-1; UL listed
