Snap Action Switch - BA Series, SPDT, Roller Plunger, 20A, Screw Terminal BA-2RB-A2

Rated for operation within specified parameters, the Honeywell Snap Action Switch from the BA Series is configured to operate within the specified differential travel range. This large snap-action switch features an overtravel roller plunger actuator and a single-pole double-throw (SPDT) contact form. It is constructed with a phenolic housing and utilizes screw terminals for electrical connections.Key Features:- AC Contact Rating: 20 A at 480 V- DC Contact Rating: 0.5 A @ 125 V, 0.25 A @ 250 V- Actuator Type: Overtravel roller plunger; actuator length of 1.94"- Operating Force: Minimum 14 ozf, maximum 22 ozf; release force of 10 ozf- Differential Travel: Minimum 0.002 in, maximum 0.0075 in- Pretravel Maximum: 0.05 in; overtravel of up to 0.094 in- Body Dimensions: Width/length of 1.94", height of 0.95", depth of approximately 0.06"- Mounting Hole Distance: Center-to-center spacing of 1" with mounting hole diameter at #8 (1/8") - Electrical Connection: Bottom-facing screw terminal (6–32 x .218 in.) with cup washer- Operating Temperature Range: -67°F to +185°F (-55°C to +85°C)- Standards Met: CE, CSA, ENEC, UL Listed
