Snap Action Switch - SPDT, Roller Lever, 15A, Phenolic Body, BZ Series BZ-2RW82212-A2

Rated for consistent on/off actuation within specified parameters, the Honeywell BZ Series Industrial Snap Action Switch is configured for on/off actuation as specified; suitable for use in a range of compatible applications. This switch features a short roller lever actuator with spring return action, housed in a phenolic body measuring 1.94 inches wide by 1 inch high by 0.7 inches deep. It offers single-pole double-throw (SPDT) contact configuration and supports both AC and DC ratings up to 15A at 240V AC. Key Features: - Actuator: Short roller lever, 1.05" length - Contact Form: SPDT (1NO/1NC) - Electrical Ratings: Up to 15A @ 240V AC; up to 0.25A @ 250V DC - Body Material: Phenolic construction - Mounting Dimensions: Center mounting holes at 1" centers; mounting hole diameter of 1/8" - Operating Force: Maximum of 6 ozf; release force of 1.5 ozf - Travel Parameters: Pretravel of 0.078", overtravel of 0.094", differential travel from 0.003" to max of 0.02" - Temperature Range: -67°F to +185°F (-55°C to +85°C) - Terminals: Bottom-facing screw terminals with cup washer (6–32 x .218") - Standards Compliance: CE, CSA, ENEC, UKCA, UL Listed
