Square D
Square D QBL22200
- SKU:
- ZO-G2305956
- UPC:
- 785901412632
- MPN:
- QBL22200
- Condition:
- New
- Weight:
- 3.35 LBS
- Shipping:
- Free Shipping
Frequently bought together:
Description
PowerPacT Q-Frame circuit breakers are used for overcurrent protection and switching on 240VAC systems. They are rated for 240VAC operational voltage and provide thermal magnetic trip protection. PowerPacT Q circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. This unit has lugs on both the line and load sides. This PowerPacT Q, 200A, 2 pole, circuit breaker has an interrupting rating of 10kA at 208Y/120VAC and 240VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT Q circuit breakers comply to UL, CSA, and NOM standards and are IEC certified.
View AllClose
Additional Information
Country of Origin: |
Korea (South) |
SubCategory: |
Electrical Supplies |
International Shipping: |
No |
Lead Time: |
Expected to ship in 1-2 business days |
Features: |
Mercury Free; PVC Free |
Related Products
Related Products
Square D QO130VH
