Ssi 2" Flanged Cast Iron Triple Duty Check Valve 0200-125TFI-B

This 2 in. triple duty check valve combines check, balancing, and shutoff functions in one inline valve for process piping systems. It features a flanged cast iron body with a disc check mechanism for reverse-flow control while supporting flow regulation and system isolation. The valve is rated for water and steam service and can be mounted horizontally or vertically. Key Features: 2 in. nominal valve size with 2 in. flange x flange connections Class 125 ANSI flanges; connection: 125 Class flange Cast iron body with straight, inline triple duty body design Disc check mechanism with single-flow design Compatible media: steam, water Cracking pressure: 0.25 psi Flow rating: 400 gpm Full flow: yes Maximum operating pressure: 200 psi Maximum steam pressure: 200 psi WSP Maximum water pressure: 200 psi at 250 degrees F Operating temperature range: 60 degrees F to 300 degrees F Seal and seat material: Buna-N Spring material: stainless steel Check type: silent check Overall dimensions: 8-3/8 in. L x 9-5/8 in. H Standard: ASME B16.1
