Sharpe
Sharpe 4371000320
- SKU:
- ZO-G508258801
- MPN:
- 4371000320
- Condition:
- New
- Weight:
- 0.01 LBS
- Shipping:
- Free Shipping
Frequently bought together:
Description
SHARPE 4371000320 is a 1/2 in. inline swing check valve with socket weld x socket weld female connections. It is configured for one-direction flow applications in steam service. The valve features a 316 stainless steel body and swing mechanism, a PTFE seal, and a metal seat. Maximum operating temperature is 350 degrees F, and maximum steam pressure is 125 psi WSP. Key Features: Inline swing check valve with 2-way design 316 stainless steel body and check mechanism 1/2 in. nominal valve and pipe size Female socket connections on both sides; socket weld x socket weld connection type Horizontal or vertical mounting orientation For steam media PTFE seal and metal seat Overall length: 2.54 in. Cap to inlet center: 1 17/20 in.; height cap to inlet center: 1 7/8 in. Check style: Standard; no counterweight MSS SP-110 standard Valve series: 2027
View AllClose
Additional Information
Country of Origin: |
China |
SubCategory: |
Plumbing |
International Shipping: |
No |
Lead Time: |
Expected to ship in 1-2 business days |
