Asco 8215C063CSA

The ASCO 8215C063CSA solenoid valve is a direct-acting, 2-way, 2-position valve with a normally open starting configuration designed for controlling the flow of air and vacuum. It features an aluminum body and a valve design: 2-Way/2-Position; direct acting. This valve operates within an ambient temperature range of 14°F to 140°F and can handle fluid temperatures up to 125°F. Environmental Rating: Hazardous, Indoor, Outdoor. It includes the coil as well as sealing components. The valve is operated at 120V AC, consuming 15.4 W of power at 60 Hz frequency. Key Features: - Valve Design: 2-Way/2-Position, normally open configuration - Valve Type: High Flow, direct acting operation - Body Material: Aluminum - Media: Air, Fuel Gas - Operating Pressure Differential: 0 psi minimum, 25 psi maximum for air, fuel gas, and water - Orifice Diameter: 1-5/8 in - Nominal Pipe Size: 1-1/4 in with NPTF inlet and outlet connections - Coil Enclosure: Without Junction Box, watertight with Class F insulation - Electrical Connections: 1/2 in conduit with 18 in leads - Voltage: 120V AC at 60 Hz - Wattage: 15.4 W - Response Time: 120 milliseconds - Environmental Rating: Hazardous, Indoor, Outdoor - Seal Material: NBR - IP Rating: IP65 - Overall Dimensions: Height 6-11/16 in, Length 5 in, Width 5-3/8 in - Includes coil and seal components - Standards: CSA, UL - NEMA Enclosure Rating: 1 - Center Line Pipe Center Size: 3-5/8 in
