Hubbell Wiring Device-Kellems HBLS430R7W

The HUBBELL Advantageâ„¢ Series Pin and Sleeve Receptacle is a 30A, 480VAC device intended for use in industrial electrical connections. It features a straight connection orientation and is compatible with IEC 60309-2 pin and sleeve devices. The receptacle functions as a disconnecting means for motor circuits and branch circuits, per applicable standards, suitable for use in demanding environments.Key Features of the HUBBELL Advantageâ„¢ Series Pin & Sleeve Receptacle: Current/Voltage Rating: Rated for 30 A at 480V AC, three-phase operationHousing Material: Valox 357 (polybutylene terephthalate)NEMA/IP Ratings: NEMA Type 4X enclosure; IP67/IP69k rated for protection against dust, water, and high-pressure washdownsOperating Temperature Range: -40°C to 75°CWire Size Compatibility: Accepts wire sizes from 12 AWG to 8 AWG via screw terminalsHorsepower Rating: Rated up to 20 hpPower Indicating Light: Includes power-indicating LEDsGrounding Style: Unswitched ground per IEC standardsFlange Type & Cap: Flanged body with spring-loaded cap for secure closureCircuit Disconnect Functionality: Functions as a disconnecting means for motor circuits and branch circuits, per applicable standardsStandards Compliance: UL Listed (File E146032), CSA Certified LR285C; UL94 V-0 flammability rating
